Unlock Your Flash Setup's Potential

Unlock the full potential of your flash setup with the Phottix Odin II TTL Flash Trigger Receiver. Compatible with Canon's E-TTL / E-TTL II flash system, the Odin II receiver has a 2.4 GHz radio system and can be used to integrate shoe-mounted flashes and studio strobes into your setup. It can be triggered by the original Odin receiver or Mitros+ flash from up to 328' away. You can also use it in a multi-system setup with Odin TTL, Strato, and Strato II receivers as well as Mitros+, Indra360, and Indra 500 lights. A major improvement over the previous model is the expansion of channels and the introduction of the Digital ID, which gives you further control over channels 5-32 to eliminate interference with other systems.

Embracing TTL communication between the camera and flash, automatic exposures can easily be made and more advanced users can take advantage of manual power and zoom control to dial in the exact look they need. Using the five groups, users can also control different groups and flashes with varying settings as well as mix and match TTL and manual units. All of this is easily accessed via the large LCD screen along with buttons for adjusting settings.

Additional features include both high-speed sync for TTL flashes as well as the proprietary OverDrive Sync mode for manual studio strobes, both of which allow users to work at shutter speeds up to 1/8000 second. Also, users will be able to remotely control the modelling light of their Indra TTL strobes as well as use an AF assist light when needed. And, it has a mini-USB port for firmware updates as well as a 3.5mm sync port and a 5 VDC power port. It can also run on two AA batteries.

  • Can be triggered using the Odin II and original Odin transmitter as well as with the Mitros+ transceiver flash with full TTL support
  • Ratio control in A: B mode from 8:1 to 1:8 in 1/2 step increments
  • Manual power control from 1/1 to 1/128
  • LED indicator light
  • Exposure compensation of ±3 EV in 1/3 step increments
  • 3.5mm sync port
  • Modelling light function
  • Locking foot with 1/4"-20
  • Runs on two AA batteries
PHOTTIX ODIN II RECEIVER

WIRELESS

Channels 32
Groups 5 (A, B, C, D, E)
Wireless Range 328' / 100 m
Radio Frequency 2.4 GHz

GENERAL

Control Modes E-TTL/E-TTL II, Manual, TTL
EV Range ±3 (1/2, 1/3 Increments)
Sync Speed 1/8000 Sec
Power Settings 1/1 to 1/128 (1/3-Stop Intervals)

CONNECTIVITY


Inputs/Outputs 1 x 1/8" / 3.5 mm (Flash)
1 x Mini-USB

ELECTRICAL

Battery Type 2 x AA

PHYSICAL

Dimensions Receiver: 8.2 x 6.9 x 4.8 cm
Weight 0.0907 kg


* Specifications subject to change by the manufacturer without notice

  • Phottix Odin II TTL Flash Trigger Receiver for Canon
