Guide Number 20 @ ISO100

With a Guide Number 20 at ISO 100, the Panasonic Lumix DMW-FL200LE can help illuminate darker environments. It is particularly suited to Micro Four Thirds camera users looking for a compact, on-camera flash solution for portrait and general purpose indoor photography.

Compatible with Panasonic TTL

The flash supports Panasonic’s TTL system to ensure accurate exposure based on the brightness detected by the camera’s lens. TTL flash output can be manually adjusted from -3EV through to +3EV in 1/3EV steps to deliver precise exposure control.

Wireless Remote Shooting

When used with Wi-Fi-compatible LUMIX cameras, wireless flash control across four channels with three groups in each channel is available. The flash can be used as a slave or as master flash with TTL support to remotely trigger other compatible flash units. This allows you to achieve exciting creative results with single and multiple on-and-off camera lighting setups.

Zoom Range of 24-100mm

With a zoom range of 24-100mm (35mm equivalent), the flash can match the focal length of a wide range of lenses in your kit. The included wide panel diffuser can help spread the light up to 14mm if you need to work with a slightly larger area.

90° Tilting for Bounce Lighting

The flash head can be tilted up to +90° allowing you to bounce the light the wall or ceiling. This helps to eliminate harsh shadows, red-eye, and hot spots, producing more natural looking lighting that’s better suited for portrait or close-up photography.

Fast Flash Duration and Recycle Time

Flash duration can be set between 1/250 and 1/50000s, equipping you with creative control over fast moving subjects. It provides up to 200 exposures on a single set of 2 AA batteries and recycles within 3 seconds (when used with 2400mAh NiMH batteries) between each full-powered exposure.

Built-in LED Light

The flash has a 200 lux output LED that provides a soft, even source of constant illumination that works well for video applications like on-camera interviews. The LED also comes in handy for creative long exposures, or as a modelling light that lets you check and adjust your flash before the shot is taken. It can also function as AF assist light in dim or difficult lighting conditions.

Ideal for MFT Cameras

It’s compact and lightweight, designed for the typically smaller Micro Four Thirds Mirrorless camera systems. The Panasonic Lumix DMW FL200LE Flash also features an elegant, leather-like finish that matches the look and feel of most LUMIX cameras, making it a great entry-level flash unit.

Power Requirements

DC 3.0 V

Batteries Recommended for Use

LR6/AA Alkaline dry batteries x 2

Batteries Recommended for Use

HR6/AA Rechargeable nickel metal hydride batteries (NiMH) x 2

Charging Time (from full flash until the [CHARGE] lamp lights)


Charging Time (from full flash until the [TEST/ CHARGE] lamp lights)

Approx. 4.0 sec: LR6 / AA Alkaline dry batteries

Charging Time (from full flash until the [TEST/ CHARGE] lamp lights)

Approx. 3.0 sec: HR6 / AA Rechargeable nickel metal hydride batteries

Charging time (from full flash until the [TEST/CHARGE] button lights)


Firing Period

Approx. 1/50,000 - 1/250 sec

Firing Period

(varies depending on the flash intensity)

Number of Flashes (with full flash)

Approx. 120 flashes : LR6/AA Alkaline dry batteries

Number of Flashes (with full flash)

Approx. 200 flashes : HR6/AA Rechargeable nickel metal hydride batteries (2,400 mAh type)

Number of Flashes (with full flash)

(differs depending on the photo taking conditions)

AF Assist Lamp

Effective distance: Approx. 1 - 5m

AF Assist Lamp

(differs depending on the digital camera and type of lens used)

Flash Mode


Guide Number

20 (ISO 100·m), 14 (ISO 100·m when the wide panel is used)

Lighting Angle

Covers the angle of view of 12mm and longer (35mm camera equivalent: 24mm and longer)

Lighting Angle

(With wide panel: 7mm and longer, 35mm camera equivalent: 14mm and longer)

Power Saving Mode


Lighting angle



Approx. 61.0 (W) x 52.5 (H) x 82.0 (D) mm


Approx. 225 g (including batteries)


Approx. 175 g (main unit)

Operating Temperature

0 - 40 °C

Operating Humidity

10 - 80 %RH (no condensation)


Wireless control is available with the DMC-GH4 / GH4R / GH3 / GX8 / GX7 / GM5 / G7 / G6 / GF6



Approx. 200 lux at 1 m

Lighting Angle


Control Mode


Continuous Light-Emitting Time


* Specifications subject to change by the manufacturer without notice

  • Panasonic Lumix DMW-FL200LE Wireless TTL Flash
  • Flash Case
  • Flash Stand
  • Wide Panel
